Interactive-flatpanel | Floor standing advertising display | Commercial display

|
| Place of Origin: | guangzhou |
| Brand Name: | wanbao |
| Certification: | CE , ISO9001,RHOS |
| Model Number: | LED75H7 |
| Minimum Order Quantity: | 5PC |
|---|---|
| Price: | 880 |
| Packaging Details: | export carton |
| Delivery Time: | 7-35 working days |
| Payment Terms: | T/T |
| Supply Ability: | 1000set/month |
| Type: | Whiteboard | Resolution: | 3840*2160 (4K) |
|---|---|---|---|
| Frame: | Aluminum Alloy | Warranty: | 1 Year |
| System Version: | Android 9.0 | Camera Pixel: | 13m |
| Response Time: | 6ms | Product Dimension: | 1485*888*89mm |
| Writing Method: | Pen/finger Touch | Operating System:: | Android+win7/10 Optional |
| Panel Type: | LCD | Touch: | 20 Point |
| High Light: | 75" Usb Interactive Flat Panel,Education Interactive Flat Panel,Finger Touch Interactive Flat Panel |
||
Factory overview
Guangdong Deyuan Technology Co., Ltd., the headquarter is located in Guangzhou, China. Guangzhou JAV Electric Appliance Co., Ltd., and Guangzhou Raizea Intelligent Technology Co., Ltd is under Guandong Deyuan. Nowadays, Guangdong Deyuan is one of modern high-tech enterprises specialized in LED TV, smart commercial display products.
Touch Interactive Whiteboard is an interactive TV, it built-in with LCD/LED and touch screen (and PC for optional). We use the most popular technology infrared touch to achieve interaction between users and the monitor.
All in one touch monitor is also a LCD whiteboard, use the LCD to instead of the projector for image presentation.
Connect with built-in or outer PC, it is a large touch PC, fingers to control and operate the PC to present advertisement, conference PPT, classroom courses, play movies and etc…
Features of All in One Interactive Whiteboard
♦20-40 points IR touch screen
♦ Comes with multi-funtion software
♦ Comes with WIFI
♦ Equiped with multiple signal interfaces
♦ Aluminum alloy body with front access touch frame module
♦ Intelligent black board detecting features (Once black board activated, LED backlit off)
♦ Available in a wide range of sizes: 55", 65", 75"86" 98" 110''Inch optional
Product Details:
| Screen size | 55’’/65’’/75’’/86’’/100‘’/110'' |
| CPU | intel i3(intel i5/i7 option) |
| RAM | (8GB/16GB option) |
| Memory | (128GB SSD/256GB SSD option) |
| Windows OS | Windows 10 without license( license option) |
| (Android OS option) | 8th corei5(8400)8G+256G |
| Android | Android 8.0 |
| Touch Technology | Infrared touch |
| Touch points | 20 points-40points |
| Input way | finger touch,pen,or any opaque object |
| Touch life times | Over 60,000,000 times |
| Touch response speed | 8ms |
| Display Type | DLED |
| Resolution | (3840*2160 UHD option) |
| Brightness | 350(cd/m2) |
| Ratio of display | 16:09 |
| Best viewing angle | up:73 down:73； left:73 right:73 |
| Max. viewing angle | 178° |
| Contrast ratio | 5000:1TYP |
| Glass type | 4mm tempered glass |
| Glass transmittance | 95% |
| Front Buttons: | |
| PC power button*1;Power on/off*1;USB*2 | |
| Front ports: | |
| HDMI*1;Touch out*1;MV in*1 | |
| Back ports(Ⅱ):(Exact ports info. depends on the model of OPS PC) | |
| DC(9V-12V)*1;MIC*1;AUDIO*1;LAN*1;USB3.0*2;USB2.0*2;HDMI*1;VGA*1 | |
| Power of display | 200W |
| Colors | 1.07B(10bit) |
| Life time | 80,000h |
| Working voltage | 60-120HZ 100-250V |
| Standby power | ≤0.5W |
| Working temperature | 0℃~40℃ |
| Storage temperature | -20℃~60℃ |
| Working humidity | 10%~90%RH |
| Power of speaker | 8Ω10W*2 |
| Frame material | Alloy |
| Accessories | Wall bracket/movable floor stand/pen/remote control/WIFI antenna |
| Warranty | 1 year |
| Package | 3cm thickness Honeycomb box |
| SIZE | Display size (inch/mm) |
Overall size/Weight W*D*H(mm)/kg |
Packing size/Weight W*D*H(mm)/kg |
QTY of containers(pcs) 20'GP/40'GP/40'HQ |
| 55" | 1210*680 | 1262*782*85/26 | 1428*220*878/36 | 102/236/254 |
| 65" | 1428*804 | 1489*906*89/37.5 | 1656*204*1050/49.8 | 79/183/197 |
| 75" | 1650*928 | 1710*1029*89/52.3 | 1886*210*1196/66.2 | 59/137/148 |
| 86" | 1895*1066 | 1957*1169*90/69.8 | 2134*210*1334/89.4 | 53/123/133 |
| 98" | 2159*1214 | 2245*1323*90/102 | 2483*376*1493/136 | 20/47/50 |
Electronic interactive teach touch screen all in one multimedia teaching machine smart whiteboard
* Teaching: School/Education/E-learning
* Commerical: Conference/Exhibition/etc.
Fast delivery time:The goods can be shipped 1-2 working days after receiving payment for small orders.It takes 7-10 working days for bulk order after receiving payment.
Provide professional after-sales service
Returns&Warranty:
1.all the goods are inspected before shipment,so if you are not satisfied with the purchase,you can exchange the items in one week and you must contact us within 24 hours of the receipt of your purchase
2.The shipping and handling charge is not refundable and customer should be responsible for all the charges of returning and reshipping
3.All return items must be in tis original conditions,including box and accessories,men made defects are not guaranteed,such as broken scratched and so on
4.For any items pls send by EMS or your local post when send back
5.All our products' warranty is 1 year.
What can we do:
1.all of our products have proceeded aging test before shipping and we guarantee to use our products safety
2.OEM/ODM orders are warmly welcome!
